Prevent backflows in your flow stream with this inline cartridge check valve. Mounted downstream a sensitive instrument, it ensures that your liquid flows in one direction only.
1/4-28 flat-bottom connection ports. Pack of 1 unit.
General
Limit your flow stream to one direction using this 1/4-28 inline check valve. Its low cracking pressure (0.1 bar) ensures a complete blockage of backflows, even at low flow rates.
Made for 1/16" OD rigid or semi-rigid tubing, fittings included.
Content
1x inline cartridge check valve
2x 1/4-28 flat-bottom nut for 1/16" OD tubing
2x 1/4-28 ferrule for 1/16" OD tubing
Specifications
| Filter materials |
PEEK, perfluoroelastomer, gold-plated stainless steel |
| Fittings material |
ETFE |
| Swept volume |
96 µL |
| Cracking pressure |
0.1 bar (1.5 psi) |
| Max. pressure rating |
69 bar (1000 psi) |
| For tubing OD |
1.6 mm (1/16") |
