Co-Flow Droplet Generator - PDMS - 30-40 µm / 1.2 mm

Name: Co-Flow Droplet Generator - PDMS - 30-40 µm / 1.2 mm
Brand: Droplet Genomics
SKU: DG-MCN-C17Q
Price: 167.8 GBP
Availability: InStock

Co-flow droplet generators to generate monodisperse emulsions, with one oil inlet, two water inlets, and one outlet. 6 devices per chip, with 1.2 mm punched holes to accommodate most tubing sizes.

The design is designed to generate droplets from 30 µm to 40 µm.

£167.80

Product SKU:: DG-MCN-C17Q

Quantity:

Available immediately

Current Stock:

Adding to cart… The item has been added

Ask an expert Talk to our engineers & PhDs

Worldwide Express Shipping

Delivery in 1-3 days for products in stock

Simplified Purchasing

Easily request a quote and track your orders.

Outstanding Support

Support by a team of Engineers and PhDs (Inhouse)

General
Content
Specifications
Documentation

General

Whereas standard ChipShop connectors only accept soft-walled tubing, this set of connectors allows connecting any 1/16" OD rigid tubing to a ChipShop chip.

Suitable for rigid tubing (PTFE, PEEK, etc.) with an OD of 1/16" (1.6 mm). Manufactured in blue TPE, max. pressure of 3.2 bar with a 1/16" OD PEEK tubing.

Plugs to block unused ports are also available in our shop.

Droplet Genomics

Co-Flow Droplet Generator - PDMS

Co-flow droplet generators to generate monodisperse emulsions, with one oil inlet, two water inlets, and one outlet. 6 devices per chip, with 0.5 mm, 1 mm, or 1.2 mm punched holes to accommodate most...

£167.80

Droplet Genomics

Flow Focusing Droplet Generator - PDMS

These microfluidic chips are based on a flow-focusing design to generate monodisperse emulsions, with one oil inlet, one water inlet, and one outlet. 6 devices per chip, with 0.5 mm, 1 mm, or 1.2 mm...

£167.80

microfluidic ChipShop

Droplet Generator with Double Cross - 20 µm and 40 µm nozzles Fluidic 1755

The Droplet Generator with Double Cross - 20 µm and 40 µm nozzles Fluidic 1755 is a specialized microfluidic chip designed for efficient production of double emulsion droplets. It features two...

£39.46 - £63.39

Chip Droplet Generator - Different droplet sizes (10-30 µm) - mini Luer - Darwin Microfluidics — Choose Options

microfluidic ChipShop

Droplet Generator with Single Cross - 10 µm to 30 µm nozzles Fluidic 947

The Fluidic 947 Droplet Generator Chip by Microfluidic ChipShop offers 8 design variations for reliable and precise production of various-sized droplets, along with mini Luer connections for...

£37.70 - £40.30

microfluidic ChipShop

Simultaneous Droplet Generator - 20 µm to 50 µm nozzles Fluidic 1751

The Simultaneous Droplet Generator - 20 µm to 50 µm nozzles Fluidic 1751 is a precise microfluidic device designed to generate droplets simultaneously across eight independent channels. It provides...

£39.46

	DG-MCN-C17Q
Nozzle width (µm)	20
Collection channel width (µm)	40
Channel height (µm)	20
Target droplet size (µm)	30-40
Material	PDMS
Dimensions	standard glass slide (75 x 25 mm)
Number of devices per chip	6
Inlets	3
Outlet	1
Punched hole size (mm)	1.2 mm
For rigid tubing OD	1.6 mm
Couplers for soft-walled tubing	18G, 16G

Co-Flow Droplet Generator - PDMS - 30-40 µm / 1.2 mm

Co-flow droplet generators to generate monodisperse emulsions, with one oil inlet, two water inlets, and one outlet. 6 devices per chip, with 1.2 mm punched holes to accommodate most tubing sizes.

The design is designed to generate droplets from 30 µm to 40 µm.
